 Product Name:DCZN-30(20A) DC Motor Controller
 Info:

Item No.:RY11-03

1.Introduction

      The DCZN 30 series DC motor controller built in board DS30 series based on the increase in external

analog compensation port, interface using the plug in enables more convenient wiring. A DC servo control

method, the realization of the motor current and speed double closed loop control, with speed control system

setting parameters easily and friendly interface. Accurate motor current reading with perfect fault protection

function, so that by the control motor steady work in rated parameters, professional EMC EMI design enhances

the control board for industrial environment get used to ability, reduce speed control board failure probability,

thus bring users use the convenience, also greatly enhance the price performance of the board.



2.Parameters

1. Working voltage: AC220V±10%  50HZ

2. Output current: 0 ~20A

3. Scope of speed regulating : 0 ~ 100

4. Adapted motor maximum power: 3KW

5. Output voltage of armature : 0~DC200

6. Output voltage of excitation :DC200V

7. Exterior dimensions (L x W x H): 265mm*115mm*285mm

8. Wire connecting mode :plug-type
